| Sensitivity |
Detect a leak of 0.1mm at 3 bars at 20m |
| Camera |
Colour 640x480 pixels |
| Display |
LCD colour 3.5" 320x240 pixels |
| Pictures |
JPEG, number date and time |
| Dynamic Target |
Yellow square with cross on light leak |
| Measurements |
dB RMS and MAX |
| Memory |
Up to 1000 pictures, can be downloaded to PC |
| Communication |
USB cable supplied |
| US sensor |
Open type
| Bandwidth +/- 2kHz à -6 dB |
| Central frequency 40kHz +/- 1kHz |
| Adjustable frequency mixer from 34 to 46 kHz |
| Auto gain, and adjustable from 50 to 110 dB | |
| Headset |
Adjustable volume from 0 to 10 |
| Power supply |
Lithium-ion rechargeable battery |
| Autonomy |
6 hours |
| Temperature range |
-10°C to + 50°C |
| Dimensions |
230mm x 100mm x 70mm |
| Weight |
580g LKS1000 alone, with metallic case 3,9 kg |
| Software |
LEAKVIEWER picture download |
| Standards CE |
CEM 2004/108/CE: EN61000-6-4 & EN61000-6-2 |
| Accessories |
LKSFLEX Flexible 400mm US sensor, LKSPROBE Mechanical US sensor and LKSCOVER Holster |
